Replace a job's plan

PUT

Update a job’s entire execution plan

Path parameters

jobIdstringRequired

ID of job to return

Headers

X-Disable-Hooks"true"RequiredDefaults to true

Request

This endpoint expects an object.

fieldMappinglist of objectsRequired

fileIdstringRequired

File ID

jobIdstringRequired

Pipeline Job ID

unmappedDestinationFieldslist of objectsRequired

unmappedSourceFieldslist of objectsRequired

programIdstringOptional

Response

This endpoint returns an object.

dataobject

The job/plan tuple that contains the full plan and the jobs status

PUT

1 curl -X PUT https://api.x.flatfile.com/v1/jobs/us_jb_YOUR_ID/plan \
2      -H "X-Disable-Hooks: true" \
3      -H "Authorization: Bearer <token>" \
4      -H "Content-Type: application/json" \
5      -d '{
6   "fieldMapping": [
7     {
8       "sourceField": {
9         "type": "string",
10         "key": "firstName"
11       },
12       "destinationField": {
13         "type": "string",
14         "key": "firstName",
15         "label": "First Name"
16       }
17     },
18     {
19       "sourceField": {
20         "type": "string",
21         "key": "lastName"
22       },
23       "destinationField": {
24         "type": "string",
25         "key": "lastName",
26         "label": "Last Name"
27       }
28     }
29   ],
30   "fileId": "us_fl_YOUR_ID",
31   "jobId": "us_jb_YOUR_ID",
32   "unmappedDestinationFields": [
33     {
34       "destinationField": {
35         "type": "string",
36         "key": "email",
37         "label": "Email"
38       }
39     }
40   ],
41   "unmappedSourceFields": [
42     {
43       "sourceField": {
44         "type": "string",
45         "key": "email"
46       }
47     }
48   ]
49 }'

200Updated

1 {
2   "data": {
3     "job": {
4       "createdAt": "2023-10-30T20:04:28.556Z",
5       "id": "us_jb_YOUR_ID",
6       "operation": "submitAction",
7       "source": "us_wb_YOUR_ID",
8       "type": "workbook",
9       "updatedAt": "2023-10-30T20:04:32.075Z",
10       "config": {},
11       "destination": "us_wb_YOUR_ID",
12       "environmentId": "us_env_YOUR_ID",
13       "fileId": "us_fl_YOUR_ID",
14       "finishedAt": "2023-10-30T20:04:32.074Z",
15       "info": "Starting job to submit action to webhook.site",
16       "input": {},
17       "managed": true,
18       "mode": "foreground",
19       "outcome": {
20         "message": "Data was successfully submitted to Webhook.site. Go check it out at https://example.site/example."
21       },
22       "progress": 100,
23       "startedAt": "2023-10-30T20:04:29.453Z",
24       "status": "complete",
25       "subject": {
26         "type": "resource",
27         "id": "us_wb_YOUR_ID"
28       },
29       "trigger": "immediate"
30     },
31     "plan": {
32       "fieldMapping": [
33         {
34           "sourceField": {
35             "type": "string",
36             "key": "firstName"
37           },
38           "destinationField": {
39             "type": "string",
40             "key": "firstName",
41             "label": "First Name"
42           },
43           "preview": [
44             "John",
45             "Suzy",
46             "Joe"
47           ],
48           "metadata": {
49             "certainty": "absolute",
50             "confidence": 1,
51             "source": "exact"
52           }
53         },
54         {
55           "sourceField": {
56             "type": "string",
57             "key": "lastName"
58           },
59           "destinationField": {
60             "type": "string",
61             "key": "lastName",
62             "label": "Last Name"
63           },
64           "preview": [
65             "Smith",
66             "Que",
67             "Montana"
68           ],
69           "metadata": {
70             "certainty": "absolute",
71             "confidence": 1,
72             "source": "exact"
73           }
74         }
75       ],
76       "unmappedSourceFields": [],
77       "unmappedDestinationFields": []
78     }
79   }
80 }
